Syntek Customizable Multi-Frequency RFID Access Control Card

Syntek Customizable Multi-Frequency RFID Access Control Card

Size:85.5*54mm
Frequency:13.56Mhz/125Khz/860-960Mhz
Color:Blank
Product Name:RFID Card Access Control
Send Inquiry
Chat Now

For access control integrators and B2B procurement

One credential for the access systems your project needs to support.

Syntek RFID access control cards offer LF, HF and UHF options, with custom dual or tri frequency builds for projects using different reader technologies. Specify the interfaces your installation requires, then verify the selected card before committing to a bulk order.

85.5 × 54 mm format · Blank white base · Passive operation · Printing and encoding options

Request a Syntek access card quote Compare card configurations

Not sure which configuration to choose? Start with your reader model or existing credential details.

RFID access control card with a visible antenna inlay on a white card body

A card and antenna example from the product range. The chip and antenna arrangement depend on the configuration ordered.

Choose the interfaces first

Compare LF, HF and UHF cards for your access control project

The right configuration starts with the readers at your doors, amenity entrances and vehicle gates. For an integrator replacing credentials across an existing site, a combined build is useful only when each interface matches the system it must serve.

Use this selection guide to define the scope of your RFID card inquiry.



Option Where to assess it What your sourcing brief should include
125 kHz LF Existing proximity access points using LF credentials Reader model and the existing card type or credential format
13.56 MHz HF Door readers and smart credential systems operating at HF Required chip, protocol and any system specific encoding requirements
860–960 MHz UHF Vehicle gates and other access points requiring UHF credentials Reader model, deployment country and required reading position or distance
Dual or tri frequency Sites where the same user needs access through different reader technologies Every required interface and the reader details for each access point

Frequency alone does not confirm compatibility or security features. The selected chip, credential format and system configuration must also match. Check reading distance with the proposed card on your actual installation.

Ask Syntek to review your multi-frequency RFID card requirements before you choose the build. If your project needs two interfaces, you can also compare the dedicated dual frequency RFID card options.

Discuss my reader requirements

RFID access card specifications for your purchasing brief

Use these product details as the starting point for a purchase specification. Confirm the final chip combination, personalization and acceptance requirements in the quotation.

Product Customizable multi-frequency RFID access control card
Dimensions 85.5 × 54 mm
Available frequency bands 125 kHz, 13.56 MHz and 860–960 MHz
Configuration options Single frequency options and custom combinations of two or three frequencies
Base appearance Blank white
Power source Passive operation using energy from the reader field; no internal battery
Primary use Contactless access control

Material, thickness, chip model and reading distance are configuration details to confirm for your order.

Match the purchase to the rollout

Custom access cards for integrators, distributors and site operators

Integrators managing mixed reader systems

For an upgrade or phased rollout, map the readers that will stay in service alongside the new equipment. Custom access credentials can combine the required interfaces so users may carry one card across supported access points.

Give Syntek your reader list and existing credential requirements to review the proposed build before sampling.

Distributors sourcing cards for multiple customers

Separate wholesale RFID card orders by each customer's technical requirements. Similar looking white cards can require different chips or credential formats.

Agree a configuration for each order, including printing, encoding and packaging needs, so your customer receives the credential specified for that installation.

Operators buying for offices or residential sites

List the entrances a staff member or resident must use, including shared facilities and parking. This helps determine whether a single interface is sufficient or a combined card is appropriate.

Include those access points in sample testing before issuing credentials across the property.

Planning readers as well as cards? Review the RFID door readers and access control equipment. For a technology comparison, see the 125 kHz and 13.56 MHz access credential guide.

Define the finished credential

OEM RFID card printing and encoding with Syntek

Order blank white cards or discuss custom printed access cards that combine your visual identity with the agreed electronic configuration. For an employee badge program, artwork approval and reader compatibility are separate checks; both belong in the purchasing brief.

  • Appearance: provide the artwork and indicate which faces need printing.
  • Data: describe any numbering or encoding required for your system.
  • Construction: confirm material, thickness and any attachment requirements before artwork or sample approval.

Syntek's OEM RFID card service supports logo printing, encoding and packaging review. Explore custom smart card printing or the broader RFID OEM and ODM manufacturing service when defining your order.

Discuss custom access card printing
White contactless cards with blue NFC text and symbol printing

Printed HF/NFC card examples shown on the original page. Printed markings do not identify the interfaces in a custom multi-frequency order.

Resolve compatibility before rollout

Approve your Syntek access card sample before bulk production

Pre-production sampling and final inspection before shipment are part of the stated quality process. Use a representative sample to confirm the card works in the intended system and matches the appearance you approve.

01 / DEFINE

Confirm the proposed build

Record the frequency combination, chip and credential requirements, quantity, artwork and any agreed encoding. Include all readers the card must support.

02 / VERIFY

Test at the actual access points

Check each required interface through the intended system. Verify presentation position and practical reading distance, then review the card's appearance and any agreed data.

03 / APPROVE

Set the bulk order reference

Approve the configuration and sample together. Agree the inspection scope and any documents your purchasing process requires before production is released.

For a multi technology credential, test each interface rather than treating one successful read as approval of the whole card. If you are comparing HF with UHF for a gate or door, review the HF and UHF RFID application differences.

Request an access card sample review
Four white RFID access cards with printed identification numbers and lanyard slots

Numbered access card examples. Confirm numbering, slot requirements and card construction for the configuration you order.

Plan the supply as well as the card

Wholesale RFID access cards with an agreed reorder specification

For recurring credential purchases, keep the approved electronic configuration alongside the artwork and encoding instructions. That gives each reorder a clear reference even when quantities or delivery destinations change.

As an RFID access card manufacturer, Syntek supports customization with an R&D team and in-house mold development. For this product, use that technical review to settle the card build before discussing the production order.

Confirm commercial terms for your configuration

MOQ and timing: request confirmation for the selected interfaces, printing and packaging. Include your required arrival date so sample approval, production and transit can be considered together.

Delivery: provide the destination and requested shipping scope. Published delivery options include FOB, CFR, CIF, EXW, CIP and DDP; confirm the applicable terms in your quotation.

Questions buyers ask before ordering RFID access cards

Can one card support our existing readers and a new access system?

A dual or tri frequency build may be suitable if the selected interfaces and credential formats meet both systems' requirements. Send Syntek the old and new reader models with existing credential details. Confirm the proposed combination through sample testing on both systems.

Can we buy blank access cards and arrange printing separately?

The listed base option is blank white. If you plan to print or personalize the cards yourself, include your printer and finishing requirements so the proposed card construction can be reviewed before ordering.

Does 13.56 MHz guarantee compatibility with our door readers?

No. The frequency identifies the band, but the chip, protocol, credential format and system setup must also match. Provide those requirements where known, or begin with the reader model and current card information.

What reading distance can we expect from the UHF option?

Reading distance depends on the selected card, reader and installation. Specify where the card will be carried or presented and the distance your application requires. Validate the result with the proposed sample before approving the UHF access credential.

What is the minimum order for custom RFID cards?

MOQ depends on the card configuration and customization scope. Include your quantity, frequency combination, artwork and packaging requirements in the inquiry so Syntek can confirm the minimum for that order.

What should we send to get a useful bulk quotation?

Start with the quantity, reader models or existing card details, required interfaces, and blank or printed preference. Add the destination and required arrival date. If the chip or encoding is undecided, identify it as a point for technical review.

Turn the requirement into a defined order

Get a Syntek RFID access control card quote for your project

Buying for an installation, a distribution customer or several properties? Send your requirements to the Syntek access card team for configuration and pricing review.

Reader or current card details

Include the interfaces that must work.

Quantity and personalization

Blank or printed, with any encoding needs.

Destination and required date

Include packaging or shipment requirements.

Request a project quotation Email the Syntek RFID card team

Still identifying the credential? Include what you know and flag the details you need help confirming.
