Waterproof NFC Keyfob for Corporate Attendance Management

Waterproof NFC Keyfob for Corporate Attendance Management

Size:40*32mm
Chip:NTAG213
Memory:144bytes
Frequency:13.56mhz
Product name:Waterproof NFC Keyfob for Corporate Attendance Management
Application:for Corporate Attendance Management
Send Inquiry
Chat Now

Product Introduction:

This waterproof NFC keyfob (40×32 mm) features an ultrasonic-sealed ABS housing and an embedded 13.56 MHz NTAG213 chip compliant with ISO 14443A protocols. Equipped with 144 bytes of user memory and an enlarged coil, it delivers a 2–5 cm reading distance across extreme temperatures from -20°C to 75°C. Engineered for high-frequency tapping, it serves corporate attendance management, access control, public transit, parking lots, ski resorts, ticketing, all-in-one card payments, and product identification.

Use the integrated reinforced metal ring on the key fob to securely attach it to a power tool-via its cooling vents, a metal loop on the handle, or an existing attachment point.

Built for extreme durability (high-strength ABS housing with ultrasonic sealing): The rugged ABS shell protects the internal chip from damage, even if the tool is dropped into a muddy puddle or subjected to high-impact collisions-eliminating the wear-and-tear issues common with paper or adhesive labels.

Instant, touch-based inspection (ISO 14443A protocol; 144 bytes of memory): Field managers don't need expensive, specialized card readers. Simply tap an Android phone or iPhone against the key fob (responsive detection within 2–5 cm) to instantly access the cloud-based work order page, allowing for one-tap assignment to a user and completion of safety inspection checklists.

Color-coded management based on risk/status (multiple colors available): Green indicates "inspected and safe for use," red signifies "awaiting repair/out of service," and yellow denotes "requires periodic calibration"-enabling safety officers to identify and prevent the unauthorized use of equipment at a single glance.



Product Parameter:

Material ABS Plastic
Size 40*32mm
Chip NTAG213
Memory 144bytes
Frequency 13.56MHz
Protocol ISO14443A
Data Retention 10 years
Write Endurance 100,000 cycles
Weight 5g
Reading Distance 2~5cm
Working Temperature -20℃~75℃

Chip, Frequency and Protocol Matched to Each NFC Keyfob



3 versions NFC chip of this fob use the same chip type and  frequency,the only difference is chip memory.



Chip Frequency Protocol Memory Best For
NTAG213 13.56 MHz ISO/IEC 14443-A 144bytes
NTAG215 13.56 MHz ISO/IEC 14443-A 504bytes
NTAG216 13.56MHz ISO/IEC 14443-A 888bytes



Factory-Tested 13.56MHz Key Fobs Checked Before Every Shipment



Each production batch passes at least three full inspections before it leaves the factory. Here is what we check and the conditions behind each figure, so your engineers can compare them with your own hardware.



Check Result Conditions
Frequency 13.56 MHz Chip response verified on an ISO14443A reader before encoding
Read range 2~5cm Fob face parallel to the reader antenna; actual distance depends on antenna size and RF power
Data integrity Pass UID read back and encoded sectors verified against your approved file
Appearance Pass Print position, colour against approved sample, shell finish and ring hole





Genuine NXP NTAG213 Chip for Universal Compatibility & Data Security Built with an authentic NXP NTAG213 IC operating at 13.56MHz, this keyfob complies fully with ISO/IEC 14443A and NFC Forum Type 2 standards. It works seamlessly across all NFC-enabled iOS/Android smartphones and commercial RFID readers without compatibility glitches. With 144 bytes of user-accessible memory and password-protection support, your access credentials or URLs stay secure against unauthorized rewriting, drastically reducing on-site technical support tickets for your team.

NFC Keyfob





How To Choose Correct NFC Chip for Your Project ?

1. NTAG213 (144 Bytes) - The Industry and Commercial Volume Leader

With a capacity of 144 bytes-sufficient for a short URL (including parameters) or a verification code-the NTAG213 is the primary choice for B2B engineering projects and commercial promotions, accounting for over 70% of the market share in these sectors.

Access Control and Time & Attendance: By reading the chip's unique 7-byte serial number (UID) or storing a brief employee ID, it offers the most cost-effective and high-speed solution.

Brand Anti-Counterfeiting and Product Traceability: Applied to the packaging of items such as alcohol, cosmetics, or electronics, it can store a short verification link; consumers simply tap the tag with their smartphone to be directed to an official website for authenticity checks.

Smart Posters and Social Media Engagement: Embedded in restaurant table displays, exhibition materials, or NFC key fobs, these tags can store links to Google Reviews, Instagram profiles, or commands for automatic Wi-Fi connection.

Ticketing, Parking, and Payment Systems: Used for amusement park tickets, ski resort lift passes, or parking access cards (where the tag stores an identification code, while the backend system handles the actual billing or deduction).

2. NTAG215 (504 bytes) - Gaming peripherals and medium-capacity encrypted applications

With a capacity of 504 bytes, this chip occupies a middle-tier position. Beyond standard commercial uses, it serves a unique, essential market: it is the hardware standard specified by Nintendo for its Amiibo product line.

Gaming peripherals and collectible figurines (a core, essential use case): Nintendo Amiibo figures and game cards for the Switch and Wii U platforms must utilize the NTAG215 chip (the NTAG213 lacks sufficient capacity, while the NTAG216 is incompatible due to protocol verification mismatches).

Anti-counterfeiting and membership credentials with cryptographic signatures: When a use case requires storing a relatively long digital signature or an encrypted token directly on the tag-thereby preventing easy cloning while offline-the 144-byte capacity of smaller chips is insufficient, necessitating an upgrade to the NTAG215.

Basic records for industrial equipment inspections: Tags used for the inspection of assets such as fire hydrants or electrical distribution boxes often need to store data locally on the chip-specifically, records of recent inspections, including timestamps, inspector IDs, and status codes.

3. NTAG216 (888 bytes) - Designed for offline data storage and smart business

With a capacity of 888 bytes-sufficient for approximately 850 English characters-the NTAG216 is ideal for scenarios where internet access is unavailable or reliance on a cloud-based database is not feasible, allowing complete information to be stored directly on the chip.

NFC Smart Business Cards (vCard standard): A comprehensive digital business card (containing name, company, job title, phone number, email, address, website, and notes) typically requires 300–600 bytes. The NTAG216 is the perfect choice to store this data in its entirety; a simple tap with a smartphone triggers the contact-saving interface, eliminating the need for an internet connection or loading a webpage.

Offline Asset Lifecycle Management: For assets such as large medical devices, aerospace components, or power equipment, essential data-including manufacturing dates, core technical specifications, and maintenance/repair logs-can be written directly onto the chip. This allows engineers to access historical records using a smartphone or handheld device, even in environments without network coverage, such as underground basements or remote field locations.



Readers Commonly Paired with This Fob



Reader or Module Interface UID Read Sector Read/Write
ACR122U USB (PC/SC) Yes Yes
RC522 (MFRC522) module SPI / I²C / UART Yes Yes
PN532 module SPI / I²C / UART Yes Yes
Android phones with NXP NFC controller NFC Yes Yes
iPhone and phones with non-NXP controllers NFC Often limited Usually not supported



Not sure which applies to you? Send your reader or controller model and a Syntek engineer will confirm the right NFC Keyfob variant before quoting. Need hardware too? See our NFC reader and writer range.

Send your reader model and Syntek will ship free NFC Keyfob samples matched to your system.

Request Free Samples

Colorful keyfob

Vibrant Color-Coding & Custom Branding for Visual Management Combining sleek ergonomics with practical durability, this keyfob comes in Blue, Black, Red, Green, Yellow, and custom Pantone colors. Facility managers can assign distinct colors to separate departments, membership tiers, or access zones at a glance. We also support silk-screen logo printing, laser serial numbering, and pre-encoding, turning a simple access token into a mobile brand asset.



Custom NFC Keyfobs Built to Your OEM Project Requirements



Syntek reviews every OEM MIFARE key fob order on two tracks: what goes on the shell and what goes into the chip. Both are approved against a photo of first printing, so the production run matches what your team's requirements.

Housing and Print

  • Blue, black, red, yellow, green, gray, white or a custom Pantone colour
  • Silk screen in 1 or 2 colours, laser engraving or UV printing
  • Artwork accepted in AI, CDR or EPS



Chip and Encoding

  • NTAG213/NTAG215/NTAG216
  • UID serialization matched to the printed number
  • Encoding URL or serial number



Packaging can be individual poly bags, bulk packing or custom retail boxes. Our OEM and ODM service covers new molds and private label programmes for distributors.

Custom printing NFC Keyfobs

Planning a custom or wholesale MIFARE key fob order? Syntek's project team will plan samples, encoding and lead time around your rollout.

Start My Syntek Fob Project

What to Include in Your NFC Key Fob Quote Request



A complete specification gets you an accurate quote from Syntek on the first reply instead of three rounds of questions.

Your Ordering Checklist

  • Order quantity, and whether a pilot batch comes first
  • Chip model
  • Encoding: URL only, or serial number
  • Housing color
  • Logo artwork and printing method
  • Packaging and delivery destination

What Affects the Unit Price

  • Order quantity, with lower unit cost on larger runs
  • Printing method
  • Encoding  different URL
  • Sequential numbering or QR code and data matching
  • Custom Pantone colour versus standard colours
  • Packaging type and shipping method

100

pcs minimum order



7 to 10

business days standard lead time



12 to 15

days for orders over 10,000 pcs



AI / CDR / EPS

vector artwork for custom printing





Bulk Packaging and Shipping for Wholesale MIFARE Key Fobs



package of NFC Keyfob

Fobs are packed 100 to a bag so your installers can count and hand them out by site or by floor without re-sorting. Cartons are sized for courier and freight handling alike, and Syntek ships by DHL, FedEx or UPS, or by sea and air freight for volume orders.

100

pcs per bag



2,000

pcs per carton



38×20×28

cm carton size



12

kg gross weight





Why Integrators Source MIFARE Classic Key Fobs from Syntek



Syntek is a NFC key fob manufacturer and OEM supplier working with access control integrators, security distributors and operators of gyms, hotels and campuses. Molding, chip bonding, printing and encoding all happen in our own factory in Huaihua, Hunan, so changing your artwork or encoding file never means waiting on a subcontractor.



Own Production Lines

ABS molding, mold making, flip-chip bonding, copper wire and silk screen lines under one roof, which keeps lead times short and batches consistent.



Inspected Before Dispatch

Frequency, read range, data integrity and appearance are checked on every batch, with at least three full inspections per order.



Certified Quality

ISO 9001:2015 quality management and a CE declaration for shipments into the EU.

Syntek ISO 9001:2015 certificate    Syntek CE certificate



NFC Key Fob Questions from Procurement Teams

Q: What is the main function and memory capacity of this NTAG213 NFC keyfob?

A: This NFC keyfob operates at 13.56 MHz with an embedded NTAG213 chip offering 144 bytes of user-accessible memory for storing URLs, unique IDs, or access credentials.

Q: How do you program and use the NFC keyfob in daily operations?

A: You can write data to the keyfob using any NFC-enabled smartphone or standard 13.56 MHz reader/writer, then simply tap it within 2 to 5 cm of a terminal for instant induction.

Q: What material is the keyfob made of and is it suitable for harsh environments?

A: The housing is crafted from ultrasonic-sealed ABS engineering plastic, making it fully waterproof, impact-resistant, and reliable in temperatures ranging from -20°C to 75°C.

Q: Which devices and systems are compatible with this 13.56 MHz keyfob?

A: It complies with ISO 14443A and NFC Forum Type 2 standards, ensuring seamless compatibility with iOS and Android NFC smartphones as well as commercial RFID access readers.

Q: What industries and applications is this waterproof keyfob best suited for?

A: It is ideal for corporate attendance management, access control, public transit, parking lot management, ski resorts, event ticketing, cashless payments, and product identification.

Q: What warranty and quality assurance do you provide for bulk orders?

A: Each keyfob undergoes 100% chip and coil testing before shipment, and we provide a 1-year quality warranty with free replacement for any manufacturing defects.

Q: How long does shipping take and do you support custom logo or pre-encoding services?

A: In-stock standard colors ship within 5 to 7 business days, while custom orders with silk-screen logo printing, laser serial numbers, or data pre-encoding take12 to 15 business days.
