13.56Mhz NFC Read and Writer
Model: ACR122U
RF Standard: ISO14443A 13.56mhz
Application: read and write all 13.56mhz products
Product Introduction
The ACR122U is a PC-linked contactless smart card reader/writer.
The appearance is small and exquisite, conforms to the CCID/PC/SC standard, and can be compatible with different systems and applications.
applications:E-wallet balance inquiry, customer bonus points, identification and authentication，payment, access control, time and attendance, and mass transit.
Protocol Parameters:
Material | ABS |
Working Frequency | 13.56mhz |
Standard | ISO 14443 Type A & B, MIFARE, FeliCa, etc |
Support tags | 13.56mhz MIFARE Classic, FeliCa and NFC Tags |
Power Source | USB |
Operating Distance | Up to 5cm |
Color | White |
LED | Red and Green |
Operating Temperature | -0℃ ~ 50℃ |
Stock Temperature | -10℃ ~50℃ |
Size | 98.0 mm (L) × 65.0 mm (W) × 12.8 mm (H) |
Weight | 70g |
Package | 1pcs/box |
Application | • e-Government • e-Banking and e-Payment • e-Healthcare • Transportation • Network Security • Access Control • Loyalty Program |
Package:
100pcs/ctn
Carton size:43*30*53cm
GW:12KG
